Influence of modified additives on the properties of compressed air foam

Authors

DOI:

https://doi.org/10.15587/1729-4061.2024.310371

Keywords:

compressed air foam, modified additives, drainage time, expansion ratio, properties, compressed air foam systems

Abstract

The object of this study is the properties of compressed air foam with the use of modified additives: its drainage time and expansion ratio.

The main properties of compressed air foam that affect the effectiveness of fire extinguishing are its drainage time and expansion ratio. At the same time, a number of authors have confirmed that the introduction of chemically modified additives into the composition of water fire extinguishing substances makes it possible to increase the effectiveness of fire extinguishing.

The problem to be solved was to determine the influence of five modified additives (NH4)2HPO4, NH4H2PO4, (NH4)2СO3, K2CO3 and KCl in the concentration range of 1–5 % by mass on the expansion ratio and drainage time of the compressed air foam. The results showed that the content of additives (NH4)2HPO4, NH4H2PO4 and (NH4)2СO3 in the aqueous solution of the foaming agent does not affect its expansion ratio within the given limits. On the other hand, with K2CO3 and KCl additives, it was not possible to obtain compressed air foam with a expansion ratio of 5–20, that is, their inefficiency in compressed air foam was noted.

The characteristic dependence of the effect of (NH4)2HPO4, NH4H2PO4 and (NH4)2СO3 additives on drainage time has been determined. The greatest drainage time is characteristic of the K≈20 generation mode. The highest recorded drainage time index was established for NH4H2PO4, namely 5.45 min; for (NH4)2HPO4 the drainage time was lower by 8 %; for (NH4)2СO3 the drainage time was lower by 20 %. At the same time, with the use of (NH4)2HPO4, NH4H2PO4 and (NH4)2СO3, it is characteristic to obtain a foam with lower drainage time compared to foam of a conventional composition. Thus, for foam with a expansion ratio of K≈20, the drainage time of foam with NH4H2PO4 is lower by 17 %, with (NH4)2HPO4 by 23 %, and with (NH4)2СO3 by 33 %.

The effect of reducing the drainage time of the foam can have a decisive role in reducing its effectiveness when used for extinguishing flammable liquids due to the extinguishing mechanism but is not decisive for extinguishing solid substances. Therefore, the fire-extinguishing effectiveness of compressed air foam with modified additives during the extinguishing of solid combustible materials in comparison with the conventional CAF composition requires further study

Author Biographies

Stanislav Shakhov, National University of Civil Defence of Ukraine

PhD

Department of Engineering and Rescue Machinery

Stanislav Vynohradov, National University of Civil Defence of Ukraine

PhD, Associate Professor

Department of Engineering and Rescue Machinery

Anatoly Kodryk, Institute of Public Administration and Research in Civil Protection

PhD, Senior Researcher

Department of Fire Extinguishing and Liquidation of Emergency Situations

Oleksandr Titenko, Institute of Public Administration and Research in Civil Protection

PhD, Senior Researcher

Department of Fire Extinguishing and Liquidation of Emergency Situations

Andrii Melnychenko, National University of Civil Defence of Ukraine

PhD

Department of Logistics and Technical Support of Rescue Operations

Dmytry Hryschenko, National University of Civil Defence of Ukraine

Department of Engineering and Rescue Machinery

Evgen Grinchenko, Kharkiv National University of Internal Affairs

PhD, Associate Professor

Research Laboratory on the Problems of Information Technologies and Combating Crime in Cyberspace

Liudmyla Knaub, Odesa Military Academy

Doctor of Technical Sciences, Professor

Department of Engineering Mechanic

References

  1. Dubinin, D., Korytchenko, K., Lisnyak, A., Hrytsyna, I., Trigub, V. (2018). Improving the installation for fire extinguishing with finely­dispersed water. Eastern-European Journal of Enterprise Technologies, 2 (10 (92)), 38–43. https://doi.org/10.15587/1729-4061.2018.127865
  2. Ostapov, K., Kirichenko, I., Senchykhin, Y., Syrovyi, V., Vorontsova, D., Belikov, A. et al. (2019). Improvement of the installation with an extended barrel of cranked type used for fire extinguishing by gel-forming compositions. Eastern-European Journal of Enterprise Technologies, 4 (10 (100)), 30–36. https://doi.org/10.15587/1729-4061.2019.174592
  3. Li, Z., Zhu, H., Zhao, J., Zhang, Y., Hu, L. (2022). Experimental Research on the Effectiveness of Different Types of Foam of Extinguishing Methanol / Diesel Pool Fires. Combustion Science and Technology, 196 (12), 1791–1809. https://doi.org/10.1080/00102202.2022.2125306
  4. Fu, X. C., Xia, J. J., Chen, Y., Jing, L. S., Bao, Z. M., Chen, T. et al. (2017). Comparison of two analysis methods on bubble size distribution. IOP Conference Series: Materials Science and Engineering, 231, 012181. https://doi.org/10.1088/1757-899x/231/1/012181
  5. Cheng, J., Xu, M. (2014). Experimental Research of Integrated Compressed Air Foam System of Fixed (ICAF) for Liquid Fuel. Procedia Engineering, 71, 44–56. https://doi.org/10.1016/j.proeng.2014.04.007
  6. Rie, D.-H., Lee, J.-W., Kim, S. (2016). Class B Fire-Extinguishing Performance Evaluation of a Compressed Air Foam System at Different Air-to-Aqueous Foam Solution Mixing Ratios. Applied Sciences, 6 (7), 191. https://doi.org/10.3390/app6070191
  7. Lee, Y.-K., Kim, Y.-S., Rie, D.-H. (2017). A Evaluation for Foaming Performance of Compressed Air Foam Using Synthetic Surfactant Fire Extinguishing Agent. Journal of the Korean Society of Hazard Mitigation, 17 (4), 189–196. https://doi.org/10.9798/kosham.2017.17.4.189
  8. Xu, Z., Guo, X., Yan, L., Kang, W. (2020). Fire-extinguishing performance and mechanism of aqueous film-forming foam in diesel pool fire. Case Studies in Thermal Engineering, 17, 100578. https://doi.org/10.1016/j.csite.2019.100578
  9. Sheng, Y., Jiang, N., Sun, X., Lu, S., Li, C. (2017). Experimental Study on Effect of Foam Stabilizers on Aqueous Film-Forming Foam. Fire Technology, 54 (1), 211–228. https://doi.org/10.1007/s10694-017-0681-z
  10. Sheng, Y., Lu, S., Xu, M., Wu, X., Li, C. (2015). Effect of Xanthan Gum on the Performance of Aqueous Film-Forming Foam. Journal of Dispersion Science and Technology, 37 (11), 1664–1670. https://doi.org/10.1080/01932691.2015.1124341
  11. Farida, F. M., Kusumohadi, C. S., Fikri, M. F. (2023). Nozzle diameter and expansion ratio of compressed air foam system. Journal of Physics: Conference Series, 2596 (1), 012004. https://doi.org/10.1088/1742-6596/2596/1/012004
  12. Chen, T., Fu, X., Bao, Z., Xia, J., Wang, R. (2018). Experimental Study on the Extinguishing Efficiency of Compressed Air Foam Sprinkler System on Oil Pool Fire. Procedia Engineering, 211, 94–103. https://doi.org/10.1016/j.proeng.2017.12.142
  13. Li, H., Yu, X., Song, Y., Li, Q., Lu, S. (2023). Experimental and numerical investigation on optimization of foaming performance of the kenics static mixer in compressed air foam system. Engineering Applications of Computational Fluid Mechanics, 17 (1). https://doi.org/10.1080/19942060.2023.2183260
  14. Shakhov, S., Vinogradov, S., Grishenko, D. (2023). Analysis of ways to increase the efficiency of compressed air foam for extinguishing solid materials. Series: Engineering Science and Architecture, 1 (175), 151–159. https://doi.org/10.33042/2522-1809-2023-1-175-151-159
  15. Kodrik, A., Titenko, O., Vinogradov, S., Shakhov, S. (2023). Improvement of the Prototype of the Compressed Air Foam System and its Testing. Applied Mechanics and Materials, 917, 59–68. https://doi.org/10.4028/p-sj8kwy
