Resistance of In2О3–p-InSe photoconverter to different types of irradiation

Authors

  • Олег Миколайович Сидор Chernivtsi Department of the Institute of Materials Science Problems of NAS of Ukraine I. Vil’de 5, Chernivtsi, 58001, Ukraine

DOI:

https://doi.org/10.15587/1729-4061.2012.6020

Keywords:

layered crystal, indium selenide, gamma radiation, electron radiation, neutron radiation

Abstract

The article presents the results of irradiation of In2O3–p-InSe photoconverters by braking γ-quanta, high-energy electrons and gamma-neutrons. In particular, their electrical and photoelectrical parameters were analyzed. The latest were compared to the similar parameters of test solar IТО–SiO2n-Si element. For the initial doses, depending on the type of irradiation, the major changes consisted in:

- the improvement of the rectification factor K at 10-100% and the monochromatic volt-watt sensitivity SU at 18-44%;

- the maintenance or increase of voltage of idle running Uхх;

- the increase of the short-circuit current Jкз at 7% ( under the action of gamma-neutrons and electrons) and the monochromatic ampere-watt sensitivity of SI at 11-28% ( under the action of γ-quanta and electrons).

In other cases, the listed parameters have been experiencing the minimal decline (up to 5%). The imperfection coefficient ВАХ n has remained constant or has even slightly improved (under the action of gamma-neutron). With further radiation, it was fixed: values ​​ Uхх, Jкз, SU and SI were saved in case of γ-quanta; Uхх and SU increased under the action of electrons, K value was significantly improved and Uхх was unchanged in case of gamma neutrons. The decline of the rest of the parameters was in the range 2-12%.  The specific changes in the spectral contours of photoresponse were not detected (except the irradiation by electrons). The possible mechanisms of radiation damages were discussed. In case of γ- and electron radiation, this is the generation of point defects - Frenkel pairs, in case of neutron radiation - formation of vacancy and internodal clusters. At the same time, the used doses and types of radiation have caused severe damage of IТО–SiO2–n-Si structure

Author Biography

Олег Миколайович Сидор, Chernivtsi Department of the Institute of Materials Science Problems of NAS of Ukraine I. Vil’de 5, Chernivtsi, 58001

Researcher

References

  1. Kovalyuk, Z.D. Intrinsic conductive oxide–p-InSe solar cells [Текст] / Z.D. Kovalyuk, V.M. Katerynchuk, A.I. Savchuk, O.M. Sydor // Mater. Sci. Eng. B. – 2004. – V. 109. – P. 252–255.
  2. Савицкий, П.И. Анизотропия электропроводности в моноселениде индия [Текст] / П.И. Савицкий, З.Д. Ковалюк, И.В. Минтянский // Неорганические материалы. – 1996. – Т.32, №4. – С. 405–409.
  3. Bakhtinov, A.P. Formation of nanostructure on the surface of layered inse semiconductor caused by oxidation under heating [Текст] / A.P. Bakhtinov, Z.D. Kovalyuk, O.N. Sydor, V.N. Katerinchuk, O.S. Litvin // Physics of the Solid State. –2007. – V. 49, N. 8. – P. 1572–1578.
  4. Вавилов, В.С. Радиационные эффекты в полупроводниках и полупроводниковых приборах [Текст] / В.С. Вавилов, Н.А. Ухин. – М.: Атомиздат, 1969 – 310 c.
  5. Balitskii, O.A. Thermodinamic study of AIIIBVI compounds oxidation [Текст] / O.A. Balitskii, V.P. Savchyn // Materials Science in Semiconductor Processing. – 2004. – V. 7. – P. 55–58.
  6. Alekperov, O.Z. Interband photoconductivity in layer semiconductors GaSe, InSe and GaS [Текст] / O.Z. Alekperov, M.O. Godjaev, M.Z. Zarbaliev, R.A. Suleymanov // Solid State Communication. – 1991. – V. 77, N. 1. – P. 65–67.
  7. Alekperov, O.Z. Intermediate type excitons in schottky barriers of A3B6 layer semiconductors and UV photodetectors [Текст] / O.Z. Alekperov, N.M. Guseinov, A.I. Nadjafov // Phys. stat. sol. (c). – 2006. – V. 3, N. 8. – P. 2669–2672.
  8. Ahmed, S.N. Physics and engineering of radiation detection [Текст] / S.N. Ahmed. –London: Academic Press, 2007 – 764 p.

Published

2012-12-25

How to Cite

Сидор, О. М. (2012). Resistance of In2О3–p-InSe photoconverter to different types of irradiation. Eastern-European Journal of Enterprise Technologies, 6(12(60), 11–15. https://doi.org/10.15587/1729-4061.2012.6020

Issue

Section

Sensory semiconductor devices
